The EnviroGrate square mesh patterns have the advantage of cost for a one-inch thick fiberglass grating along with the fabrication advantages of the square mesh pattern. It is good for flooring, machine housings, fabrications and similar applications requiring strength in both length and width directions.

Resin systems available:

• General Purpose-Polyester*
• Isophthalic-Polyester*
• Vinyl Ester

*Also available in resins that meet USDA certification requirements.

Physical Dimensions:

• Center-Center: 1.5″ x 6.0″
• Bar Height: 1.5″
• Tie Bar Width: 0.3125″
• Bearing Bar Width: 0.5625″
• Open Area: 72%
• Panel Wt. (4′ x 12′) (Men./Grit): 140/165 lbs
• Wt/sf (Men./Grit): 4.0/4.5 lbs./sf

* Available in both Grit and Meniscus Surfaces
